Architectural graphics / Francis D.K. Ching.

By:

Ching, Francis D. K., author

Material type:

TextPublication details: Hoboken : John Wiley & Sons, Inc., c2015.Edition: Sixth editionDescription: vi, 266 pages : illustrations ; 27 cmISBN:

9781119035664

Subject(s):

LOC classification:

CIR NA 2700 C45 2015

Contents:

Preface -- Drawing tool and materials -- Architectural drafting -- Architectural drawing systems -- Multiview drawings -- Paraline drawings -- Perspective drawings -- Rendering tonal values -- Rendering context -- Architectural presentations -- Freehand drawing -- Index

Summary: This guide offers an introduction to using graphic tools and drafting conventions to translate architectural ideas into effective visual presentations, using drawings to illustrate the topic effectively. This updated edition includes new information on orthographic projection in relation to 3D models, and revised explanations of line weights, scale and dimensioning, and perspective drawing to clarify some of the most difficult concepts. New examples of modern furniture, APA facilities, and presentation layout provide more up-to-date visuals, and the Reference Center features all new animations, videos, and practice exercises.
